SRU9508H3 (ALN-9640)

Advanced UHF Solution for RFID Asset Management ALN-9640 Label

The ALN-9640 RFID Tag is engineered for robust and reliable asset management. Utilizing advanced UHF technology, this RFID tag delivers fast and accurate asset tracking, making it an ideal choice for inventory control, supply chain management, and industrial asset monitoring.

Designed with durability in mind, the ALN-9640 withstands harsh environments while ensuring consistent performance. Its compact design allows seamless integration into various assets, making it suitable for use in warehouses, retail, manufacturing, and logistics.

Key Features:

  • Advanced UHF RFID Technology (860-960 MHz) for extended read range and high-speed data capture
  • Optimized for Asset Management with high read sensitivity for fast, accurate tracking
  • Durable Construction suitable for industrial, commercial, and outdoor applications
  • Compact Design for easy integration into diverse asset types
  • Ideal for inventory control, supply chain management, and asset tracking
INQUIRY
INQUIRY
Datasheet
RFID Asset Tracking Management​
rfid asset management solution
rfid asset management tracking
rfid fixed asset management
Physical Specification
Item
SRU9508H3 (ALN-9640)
Antenna size
94.8*8.15 mm
Tag size
98*11 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
860-960 MHz (Global)
IC Type
Alien Higgs 3
Memory
Higgs 3: EPC-96(up to 480) bits; User-512 bits; TID-64 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
6 m to 10 m (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
Used for asset management, etc.
