SRU4644H3 (ALN-9634)

ALN-9634 RFID UHF Solution for Pharmaceutical & Large Item Tracking

The ALN-9634 RFID Tag is a premium UHF RFID tag designed specifically for tracking pharmaceuticals and larger items across various environments. Featuring high read sensitivity and durability, this RFID tag is perfect for managing pharmaceutical inventory, medical equipment, and large industrial assets.

With its robust construction, the ALN-9634 ensures reliable performance in demanding conditions, making it ideal for warehouse management, supply chain monitoring, and asset tracking. Its larger form factor is designed to accommodate tracking needs for bigger items and sensitive pharmaceuticals that require secure and precise identification.

Key Features:

  • UHF RFID technology (860-960 MHz) for long-range, high-speed tracking of large items and pharmaceuticals
  • Enhanced read sensitivity for accurate and reliable asset tracking in various environments
  • Durable design for harsh environments and high-value asset protection
  • Optimized for pharmaceutical inventory and large item tracking
  • Ideal for supply chain management, inventory control, and asset tracking in healthcare and logistics

Ensure optimal asset tracking and inventory management with the ALN-9634 RFID Tag—designed to meet the demands of the pharmaceutical industry and large item handling

INQUIRY
INQUIRY
Datasheet
Durable Retail Clothing Labels for High-Volume Apparel
Custom Retail Clothing Labels for Brand Identity and Design
Affordable Retail Clothing Labels for Small Businesses
High-Quality Retail Clothing Labels for Fashion Brands
Physical Specification
Item
SRU4644H3 (ALN-9634)
Antenna size
46*44 mm
Tag size
49*47 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
860-960 MHz (Global), 902-928 MHz (US)
IC Type
Alien Higgs 3
Memory
Higgs 3: EPC-96(up to 480) bits; User-512 bits; TID-64 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
3 m to 6 m (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
Tracking pharmaceuticals and larger items, etc.
