SRU9954

ALN-9954 G Higgs 9 RFID Tags

The ALN-9954 G Higgs 9 RFID Tags are high-performance UHF RFID solutions designed for demanding industrial and commercial applications. Built with advanced Higgs 9 IC technology, these tags offer exceptional read range, durability, and reliability, making them ideal for asset tracking, inventory management, and access control.

what is rfid chips？

RFID (Radio Frequency Identification) chips are small devices that use radio waves to transmit and receive data. They consist of a microchip and an antenna, and can store information that can be read by an RFID reader. RFID is used in various applications such as inventory tracking, access control, and contactless payments.

Featuring the Impinj Higgs 9 IC, the ALN-9954 G RFID tags deliver industry-leading performance with a read range of up to 12 meters and fast data transfer rates. These tags are encased in a rugged, weather-resistant material, ensuring reliable operation in harsh environments. With a 96-bit EPC memory and user memory options, they provide flexibility for a wide range of applications.

The ALN-9954 G Higgs 9 RFID Tags are perfect for:

Asset Tracking: Monitor and manage high-value equipment and tools.
Inventory Management: Streamline warehouse operations with accurate and efficient scanning.
Access Control: Secure entry points in corporate offices or industrial facilities.

By integrating the ALN-9954 G Higgs 9 RFID Tags into your operations, you can:

Improve operational efficiency with fast and accurate scanning.
Reduce losses and errors in asset tracking and inventory management.
Enhance security with reliable and tamper-proof identification.

INQUIRY

Datasheet


Physical Specification
	Item	SRU9954
	Antenna size	93*19 mm
	Tag size	96*23 mm
	Thickness	11–18 mils / 279–463 microns
	Material	Paper / PP / PET or customized
	Adhesive	Solvent free permanent acrylic adhesive
	Color	White, Transparent, etc.
	Weight	0.01 g
RFID Specification	Air Interface Protocol	ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
	Operating Frequency	860-960 MHz (Global)
	IC Type	Alien Higgs 9
	Memory	Higgs 9: EPC-96(up to 496) bits; User- up to 688 bits; TID-48 bits
	Write Endurance	100,000 cycles
	Data Retention	Up to 20 years
	Read Range	5 m to 9 m (Depend on reader and environment)
	Feature	Bulk identification
Environmental Specification	Operating Temperature	-40 °C to +85 °C / -40 °F to +185 °F
	Operating Humidity	20% to 60% RH
	Recommended Storage	+25°C / 77°F, 40% RH
	Bend Diameter	> 1.97” / 50 mm
	Pressure	< 5N/mm2
	Drop Resistance	Per ASTM D5276
	Shelf Life	2 years at +25°C / +77°F, 40% RH
	ESD Voltag Immunity	±2 kV peak HBM
Other Specification	Package Detail	3000 pcs/reel, vacuumed in ESD bag or customized
	Core Size	76.2 mm / 3 in, etc.
	Delivery Format	On reel for dry inlay, wet inlay, label
	Samples Policy	For free if stock available
	Personalization	Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
	Final Inspection	100% tested, defective tags marked
	Certification	CE Approved, RoHs Approved, etc.
	Application	Used for clothing retail, etc.
