Heat Seal RFID Laundry Tags‘s capabilities are designed for robust applications in textile and garment industried laundry. These labels are ideal for industrial laundry management, allowing efficient tracking of uniforms, hospital linens, hotel fabrics, and more. Their ability to withstand high temperatures, repeated ironing, and harsh washing conditions ensures durability and reliability in demanding environments. These labels streamline inventory management, enhance process automation, and reduce human error. Additionally, they are perfect for uniform rental services, hospital fabric tracking, and military or firefighting clothing management, providing seamless integration into RFID systems for real-time monitoring and operational efficiency.
Physical Specification | ||
|---|---|---|
Item | SRULAD7015-H | |
Tag Size | 70*15mm | |
Thickness | 1.5 mm | |
Material | Polyester | |
Color | White, etc. | |
Weight | 0.6 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | NXP UCODE 8, NXP UCODE 9 | |
Memory | UCODE 9: EPC-96 bits; User-N/A; TID-96 bits UCODE 8: EPC-128 bits; User-N/A; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range (Fixed reader) | Up to 6 m (Depend on reader and environment) | |
Read Range (Handheld reader) | Up to 2 m (Depend on reader and environment) | |
Operating Specification | Typical washing cycle | Washing: +90°C (I94°F), 15 minutes Drying: +I80°C (356°F), 3 minutes lroner: +200°C (392°F), 12 seconds Water Extractor: 60 bar, 80 seconds |
Autoclave | Air removal: +I00°C (+212°F), 5 minutes, 0.1 bar Sterilizing: +134°C (+273°F), I0 minutes, 3.25 bar Drying: +45°C (+113°F), 15 minutes, 0.2 bar | |
Patching Instructions | +204°C (399°F), 12 seconds, 0.5 kg/cm2 | |
Chemical Resistance | All Chemicals common to the washing process | |
Feature | 200 washing cycles with water extractors up to 60 bar | |
Installation | Heat Sealing | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
Other Specification | Package Detail | 200 pcs/ESD bag or customized |
Delivery Format | Single unit | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Industrial washing management, Rental laundry management, Uniforms management, Medical apparel management, Military clothing management | |
