SRULAD5815

Laundry RFID Tag

Our Laundry RFID Tags are engineered to bring efficiency and precision to laundry operations. Designed to withstand harsh conditions, these tags are ideal for tracking and managing textiles in industries like hospitality, healthcare, and industrial laundries.

Benefits:

  • Reduces textile loss and operational errors.
  • Saves time and labor costs with automated tracking and sorting.
  • Increases inventory accuracy and operational productivity.
  • Provides reliable, long-term performance even in demanding environments.

Our Laundry RFID Tags are the perfect solution to modernize laundry operations, streamline processes, and achieve unparalleled accuracy and efficiency.

INQUIRY
INQUIRY
Datasheet
Physical Specification
Item
SRULAD5815
Tag Size
58*15 mm
Thickness
1.5 mm
Material
Polyester
Color
White, etc.
Weight
0.6 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
860-960 MHz (Global)
IC Type
NXP UCODE 8, NXP UCODE 9
Memory
UCODE 9: EPC-96 bits; User-N/A; TID-96 bits
UCODE 8: EPC-128 bits; User-N/A; TID-96 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range (Fixed reader)
Up to 6 m (Depend on reader and environment)
Read Range (Handheld reader)
Up to 2 m (Depend on reader and environment)
Operating Specification
Typical washing cycle
Washing: +90°C (I94°F), 15 minutes
Drying: +I80°C (356°F), 3 minutes
lroner: +200°C (392°F), 12 seconds
Water Extractor: 60 bar, 80 seconds
Autoclave
Air removal: +I00°C (+212°F), 5 minutes, 0.1 bar
Sterilizing: +134°C (+273°F), I0 minutes, 3.25 bar
Drying: +45°C (+113°F), 15 minutes, 0.2 bar
Patching Instructions
+204°C (399°F), 12 seconds, 0.5 kg/cm2
Chemical Resistance
All Chemicals common to the washing process
Feature
200 washing cycles with water extractors up to 60 bar
Installation
Sewn inside the hem or pouch
Recommended Storage
+25°C / 77°F, 40% RH
Shelf Life
2 years at +25°C / +77°F, 40% RH
Other Specification
Package Detail
200 pcs/ESD bag or customized
Delivery Format
Single unit
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested
Certification
CE Approved, RoHs Approved, etc.
Application
Industrial washing management, Rental laundry management, Uniforms management, Medical apparel management, Military clothing management
