SRU4630M4 (H41)

Omni Directional RFID Antenna for Warehouse Management Efficient Inventory Tracking & Real-Time Monitoring

An Omni Directional RFID Antenna is a powerful tool for warehouse management, offering 360-degree coverage for efficient, real-time asset tracking and inventory monitoring. Designed for high-performance environments, these antennas enable fast, reliable RFID tag readings from any direction, improving the speed and accuracy of inventory checks, order fulfillment, and stock management in warehouses and distribution centers.

When integrated with an RFID system, Omni Directional Antennas provide comprehensive, hands-free tracking, ensuring a smoother flow of goods through the warehouse, reducing manual labor, and minimizing errors. Ideal for busy warehouses with high stock turnover, this solution enhances visibility and operational efficiency.

Key Features:

  • 360-Degree Coverage: Provides full-range, omnidirectional scanning, reducing dead zones and ensuring quick, accurate readings in all directions.
  • Enhanced Inventory Accuracy: Significantly improves inventory visibility, ensuring real-time data for more accurate stock levels and reducing stock discrepancies.
  • Fast and Efficient Tracking: Tracks multiple items simultaneously, allowing for high-speed processing of goods in busy environments.
  • Scalable Solution: Easily integrates into existing RFID infrastructure, making it a scalable option for warehouses of any size.
  • Durability & Reliability: Built for tough warehouse environments, with rugged construction that ensures longevity even in challenging conditions.
Physical Specification
Item
SRU4630M4 (H41)
Antenna size
46*30 mm
Tag size
49*33 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
860-960 MHz (Global)
IC Type
Impinj Monza 4E, Impinj Monza 4D, Impinj Monza 4i, Impinj Monza 4QT
Memory
Monza 4QT: EPC-512 bits; User-128 bits; TID-96 bits
Monza 4E: EPC-128 bits; User-496 bits; TID-96 bits
Monza 4D: EPC-32 bits; User-128 bits; TID-96 bits
Monza 4i: EPC-480 bits; User-512 bits; TID-96 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
4 m to 9 m (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
Usage and Retail, etc.
