RFID cable ties are a powerful solution for managing and identifying cables, wires, and bundled assets across a wide range of industries — from data centers and telecom networks to power grids, manufacturing plants, and transport infrastructure.
Each cable tie is embedded with a UHF RFID chip that carries a unique ID, enabling non-contact, long-range scanning for asset identification, maintenance logs, and inspection workflows. These rugged ties not only fasten securely around cables but also digitally link each cable or bundle to your tracking system — ensuring complete visibility over mission-critical infrastructure.
Built-In UHF RFID Tag: Readable from several meters away with fixed or handheld readers — no need for direct access or line of sight.
Industrial-Grade Durability: UV-resistant, waterproof, heat- and chemical-resistant materials for extreme conditions.
Tamper-Evident Design: Once locked, the tie cannot be reopened without cutting — offering added security.
Fast Identification: Scan cables in tight or hazardous spaces without manual inspection.
Custom Printing Available: Combine RFID tracking with human-readable info (serials, barcodes, QR codes).
Data Centers: Identify and audit power and Ethernet cable layouts quickly, reducing downtime and human error.
Electrical Utilities: Tag cable bundles in substations, panels, or underground conduits for better maintenance records.
Manufacturing Lines: Track cabling used in machinery or robotic systems across production floors.
Oil & Gas / Railways: Manage cable networks in rugged outdoor environments with long-range scanning.
RFID cable ties offer a unique combination of physical control and digital traceability — allowing you to manage complex cable networks with unmatched accuracy, speed, and security.
Physical Specification | ||
|---|---|---|
Item | SRU4211 | |
Antenna size | 42*11 mm | |
Tag size | 45*14 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Impinj Monza R6, Impinj Monza R6-P | |
Memory | Monza R6: EPC-96 bits; User-N/A; TID-96 bits Monza R6-P: EPC-128(96) bits; User-32(64) bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 3 m to 5 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Used for jewelry, etc. |
