SRU1056M4 (E44)

RFID in Logistics and Supply Chain | Real-Time Visibility Impinj E44

In today’s fast-paced, data-driven world, RFID in logistics and supply chain management is no longer optional — it’s a competitive advantage. Radio Frequency Identification (RFID) enables real-time, automated tracking of goods across every link in the supply chain, from manufacturing and warehousing to shipping and delivery.

By embedding RFID tags on pallets, containers, or individual items, and using strategically placed RFID readers, businesses gain live visibility into inventory, streamline workflows, and drastically reduce manual errors. Whether you’re managing a global supply network or a local distribution center, RFID enhances speed, accuracy, and traceability.

Key Benefits:

  • End-to-End Visibility: Track assets in real-time across production lines, warehouses, trucks, and delivery points.

  • Faster Inbound & Outbound: Speed up receiving and dispatch processes with bulk, contactless scanning.

  • Inventory Accuracy: Reduce stock discrepancies, shrinkage, and misplaced items through automated scanning and updates.

  • Labor Efficiency: Minimize manual data entry and barcode scanning; RFID reduces reliance on human intervention.

  • Data-Driven Decisions: Gain actionable insights into stock movement, delays, and bottlenecks with RFID-powered analytics.

Applications Include:

  • Warehouse Automation: Real-time inventory levels, smart shelving, automated reordering.

  • Fleet & Shipment Tracking: Monitor cargo location, condition, and arrival times accurately.

  • Returnable Asset Management: Track reusable containers, crates, or pallets to minimize loss.

  • Cold Chain Monitoring: Integrate RFID with sensors to track temperature-sensitive goods.

From logistics to last-mile delivery, RFID is transforming supply chains into smart, responsive networks. Whether you’re scaling operations or eliminating inefficiencies, RFID gives you the visibility and control to deliver faster, smarter, and more reliably.

Physical Specification
Item
SRU1056M4 (E44)
Antenna size
105*6 mm
Tag size
108*9 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
860-960 MHz (Global)
IC Type
Impinj Monza 4E, Impinj Monza 4D, Impinj Monza 4i, Impinj Monza 4QT
Memory
Monza 4QT: EPC-512 bits; User-128 bits; TID-96 bits
Monza 4E: EPC-128 bits; User-496 bits; TID-96 bits
Monza 4D: EPC-32 bits; User-128 bits; TID-96 bits
Monza 4i: EPC-480 bits; User-512 bits; TID-96 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
5 m to 9 m (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
Used for rfid in logistics and supply chain, etc.
