Revolutionize your waste management processes with our cutting-edge RFID M750 WET Inlay. Engineered for precision and efficiency, these smart inlays provide real-time tracking and traceability, optimizing waste collection and disposal. Elevate your waste management strategy with RFID M750 WET Inlays, reducing operational costs, streamlining routes, and enhancing overall efficiency. Embrace the future of sustainable practices with technology designed to maximize control and visibility in the dynamic field of waste management. Explore a smarter way to manage waste with our state-of-the-art RFID solutions, tailored for precision, sustainability, and success in the evolving waste management landscape.
Physical Specification | ||
|---|---|---|
Item | SRU4428 | |
Antenna size | 44*28 mm | |
Tag size | 47*31 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Impinj M730, Impinj M750, Impinj M770, Impinj M775, Impinj M780, Impinj M781 | |
Memory | M730: EPC-128 bits; User-N/A; TID-96 bits M750: EPC-96 bits; User-32 bits; TID-96 bits M770: EPC-128 bits; User-32 bits; TID-96 bits M775: EPC-128 bits; User-32 bits; TID-96 bits M780: EPC-496 bits; User-128 bits; TID-96 bits M781: EPC-128 bits; User-512 bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 5 m to 12 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | For waste management, etc. |
