SRU9319

RFID On Clothes

In today’s digitally connected world, your privacy is paramount. Introducing our innovative RFID On Clothes line – where advanced security seamlessly integrates with everyday fashion. This isn’t just apparel; it’s your first line of defense against digital theft.

Our collection is engineered with a proprietary, ultra-thin metallic mesh fabric woven directly into the material. This sophisticated technology creates a Faraday cage effect, effectively blocking unauthorized radio frequency identification (RFID) and near-field communication (NFC) signals. With RFID On Clothes from our brand, you can confidently navigate crowded spaces knowing your sensitive information is protected.

How It Works:
Modern passports, credit cards, debit cards, and ID badges often contain RFID chips for convenience. However, tech-savvy thieves can use portable scanners to secretly read these chips from a distance, a process known as “skimming” or “electronic pickpocketing.” Our clothing neutralizes this threat. The built-in shielding disrupts and blocks these signals, preventing scanners from accessing the data on your chips.

Physical Specification
Item
SRU9319
Antenna size
93*19 mm
Tag size
96*22 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
860-960 MHz (Global)
IC Type
Qstar-73GB-O
Memory
Qstar-73GB-O: EPC-128 bits; User-512 bits; TID-96 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
6 m to 10 m (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
CD/DVD Management,etc.
