The Rubber Embedded RFID Tag is a durable and versatile RFID solution designed for harsh environments and demanding applications. Encased in high-quality rubber, this tag offers excellent resistance to water, dust, shock, and extreme temperatures, making it ideal for industrial, automotive, and outdoor use.
Key Features:
Robust Construction: The rugged rubber housing ensures long-lasting performance even in tough conditions.
Weatherproof & Chemical Resistant: IP67/IP68 rated for superior protection against moisture, chemicals, and UV exposure.
High-Performance RFID: Supports UHF/HF/LF frequencies (customizable) with reliable read range and fast data transmission.
Flexible Mounting Options: Can be easily embedded, attached, or molded into equipment, tires, tools, or industrial assets.
Wide Applications: Perfect for asset tracking, vehicle identification, logistics, construction, and more.
Enhance your tracking efficiency with the Rubber Embedded RFID Tag—built to endure, designed to perform!
Physical Specification | ||
|---|---|---|
Item | SRU3200 | |
Tag size | 320*125 mm, Hole: 13.5 mmx2 | |
Thickness | 30.5 mm | |
Material | Rubber | |
Adhesive | N/A | |
Color | Black, etc. | |
Weight | 1020 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 902-928 MHz (US), 865-868 MHz (EU) | |
IC Type | Impinj Monza R6-P | |
Memory | Monza R6: EPC-96 bits; User-N/A; TID-96 bits Monza R6-P: EPC-128(96) bits; User-32(64) bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range
(Fixed Reader) | Up to 3.2m – (US) 902-928MHz, on metal Up to 6.5m – (US) 865-868MHz, on metal | |
Read Range
(Handheld Reader) | Up to 1.5m – (US) 902-928MHz, on metal Up to 3.0m – (US) 865-868MHz, on metal | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
IP Rating | IP68 | |
Other Specification | Installation | Screw or backing adhesive |
Package Detail | 50 pcs/ESD bag or customized | |
Delivery Format | Single unit | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Can be applied to floors, walls and similar surfaces. Ideal for indoor and outdoor applications as it is resistant to atmospheric agents (humidity, rain, UV rays, sunlight, chemicals, dust, etc.) and mechanical requests (trampling, abrasion). |
