Sewing RFID tags into clothing provides a seamless and durable solution for tracking, inventory management, and authentication in industries like apparel retail, uniform rentals, and textile management. These tags are designed to be discreetly embedded into garments without compromising comfort or aesthetics.
Applications:
Our RFID tags for clothing offer a discreet, durable, and efficient solution for businesses looking to modernize their tracking and inventory systems while maintaining the integrity and comfort of their garments.
Physical Specification | ||
|---|---|---|
Item | SRULAD3515 | |
Tag Size | 35*15 mm | |
Thickness | 1.5 mm | |
Material | Polyester | |
Color | White, etc. | |
Weight | 0.6 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 902-928 MHz (US) | |
IC Type | NXP UCODE 8, NXP UCODE 9 | |
Memory | UCODE 9: EPC-96 bits; User-N/A; TID-96 bits UCODE 8: EPC-128 bits; User-N/A; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range (Fixed reader) | Up to 6 m (Depend on reader and environment) | |
Read Range (Handheld reader) | Up to 2 m (Depend on reader and environment) | |
Operating Specification | Typical washing cycle | Washing: +90°C (I94°F), 15 minutes Drying: +I80°C (356°F), 3 minutes lroner: +200°C (392°F), 12 seconds Water Extractor: 60 bar, 80 seconds |
Autoclave | Air removal: +I00°C (+212°F), 5 minutes, 0.1 bar Sterilizing: +134°C (+273°F), I0 minutes, 3.25 bar Drying: +45°C (+113°F), 15 minutes, 0.2 bar | |
Patching Instructions | +204°C (399°F), 12 seconds, 0.5 kg/cm2 | |
Chemical Resistance | All Chemicals common to the washing process | |
Feature | 200 washing cycles with water extractors up to 60 bar | |
Installation | Heat Sealing | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
Other Specification | Package Detail | 200 pcs/ESD bag or customized |
Delivery Format | Single unit | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Industrial washing management, Rental laundry management, Uniforms management, Medical apparel management, Military clothing management | |
