As a leading RFID manufacturer, we offer Smartrac DogBone RFID tags—an ideal solution for businesses seeking reliable, high-performance asset tracking and inventory management. Designed for durability and optimal range, these tags are perfect for a wide range of applications, from logistics to asset monitoring.
The Smartrac DogBone RFID tag features a unique shape that maximizes read range and provides excellent performance, even in dense or challenging environments. With seamless integration into existing RFID systems, these tags ensure that your business can track assets in real-time and enhance operational efficiency.
Key Benefits:
Long-Range Performance: The DogBone design ensures extended read range, making it ideal for tracking large volumes of assets over greater distances.
Durable and Robust: Engineered to withstand demanding conditions, these RFID tags maintain performance even in harsh environments.
Seamless System Integration: Easily integrates with your existing RFID infrastructure, streamlining your asset tracking processes.
Accurate and Reliable: Provides fast and accurate data for real-time visibility of assets, reducing errors and improving operational efficiency.
Versatile and Flexible: Suitable for various industries including logistics, inventory management, manufacturing, and more.
As an experienced RFID manufacturer, we provide Smartrac DogBone RFID tags that offer the reliability, performance, and durability your business needs for efficient asset tracking. Contact us today to learn more about our solutions or get started with your RFID project.
Physical Specification | ||
|---|---|---|
Item | SRU9422U | |
Antenna size | 94*22 mm | |
Tag size | 97*25 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | NXP UCODE 8, NXP UCODE 9 | |
Memory | UCODE 9: EPC-96 bits; User-N/A; TID-96 bits UCODE 8: EPC-128 bits; User-N/A; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 5 m to 12 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Used for logistics packaging, etc. |
