Transform your warehouse management with our RFID White Labels – the epitome of efficiency and precision. Engineered for seamless integration, these labels empower warehouses to streamline operations, enhance inventory accuracy, and boost overall efficiency. Elevate your logistics strategy with real-time tracking and traceability, reducing errors and optimizing resource utilization. Our RFID White Labels redefine warehouse management standards, providing a reliable solution for businesses seeking heightened control and visibility. Step into the future of warehouse efficiency with our cutting-edge RFID solutions, designed to meet the demands of dynamic and evolving supply chains.
Physical Specification | ||
|---|---|---|
Item | SRU9019 | |
Antenna size | 90*19 mm | |
Tag size | 93*22 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | NXP UCODE 8, NXP UCODE 9 | |
Memory | UCODE 9: EPC-96 bits; User-N/A; TID-96 bits UCODE 8: EPC-128 bits; User-N/A; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 5 m to 12 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | For inventory, retail management, etc. |
