SRH1808

What RFID Tag

Introducing our next-generation RFID Tag, the cornerstone of modern automated identification and data capture. Designed for durability, reliability, and exceptional read-range performance, this passive UHF tag is your ultimate solution for streamlining operations across supply chain management, inventory control, asset tracking, retail, and logistics.

Key Features & Benefits:

  • Superior Performance & Range: Engineered with a high-sensitivity microchip and optimized antenna, this RFID Tag delivers a long and consistent read range, enabling fast, bulk scanning of items without direct line-of-sight. Improve efficiency and accuracy in inventory counts by up to 90%.

  • Robust & Durable Construction: Built to withstand harsh industrial and environmental conditions. Our RFID Tag is resistant to water, dust, chemicals, and extreme temperature fluctuations, ensuring reliable performance indoors, outdoors, and in demanding manufacturing settings.

  • Universal Compatibility (UHF EPC Gen2): Compliant with global UHF protocols (860-960 MHz), this tag seamlessly integrates with all major RFID readers and systems. It is the perfect, versatile RFID Tag for creating a scalable and interoperable tracking ecosystem.

  • Flexible Application & Adhesion: Featuring a strong permanent adhesive backing, this low-profile label-style RFID Tag can be easily and securely applied to a vast array of surfaces including cardboard boxes, plastic totes, metal assets, pallets, and retail merchandise. It’s your go-to RFID Tag for tagging almost anything.

  • Large User Memory & Unique TID: Each RFID Tag comes with a substantial user-programmable memory bank, allowing you to store extensive item-specific data. The factory-locked, unique TID (Tag Identifier) guarantees absolute authenticity and enables perfect traceability for anti-counterfeiting.

  • Cost-Effective & Scalable: Priced for high-volume deployment, this highly reliable RFID Tag offers an outstanding return on investment by drastically reducing labor costs, minimizing errors, and preventing stockouts or lost assets. It is the economical choice for enterprise-scale tracking projects.

Physical Specification
Item
SRH1808
Antenna size
18*08 mm
Tag size
21*11 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 14443-A
Operating Frequency
13.56 MHz (HF)
IC Type
NXP NTAG 213, NXP NTAG 215, NXP NTAG 216
Memory
NTAG 213: EEPROM-1440 bits (180 bytes)
NTAG 215: EEPROM-4320 bits (540 bytes)
NTAG 216: EEPROM-7392 bits (924 bytes)
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
6 m to 10 m (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
CD/DVD Management,etc.
