When it comes to durable, reliable, and high-performance RFID tagging, Xerafy RFID Tags stand out as the industry benchmark. Engineered to withstand the harshest environments, these tags are designed for demanding applications where performance and durability are non-negotiable.
Why Choose Xerafy RFID Tags?
Unmatched Durability: Constructed from high-grade metals and engineered materials, Xerafy RFID Tags are built to survive extreme conditions, including high temperatures, corrosive chemicals, severe impact, and intense pressure. They are ideal for asset tracking in manufacturing, oil & gas, aerospace, and heavy machinery.
Superior Performance: Featuring advanced microchips and optimized antenna designs, Xerafy RFID Tags offer exceptional read range and accuracy, even on or near metal surfaces and liquids. This ensures reliable data capture every time.
Versatile Form Factors: From on-metal labels and rugged industrial tags to ultra-compact implants for tools, Xerafy RFID Tags come in a wide range of sizes and designs to fit your specific asset identification needs seamlessly.
Global Compliance: Xerafy RFID Tags are certified to meet global RFID standards (such as RAIN RFID), ensuring interoperability and consistent performance worldwide.
Physical Specification | ||
|---|---|---|
Item | SRU4420 | |
Antenna size | 44*20 mm | |
Tag size | 44*20 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Impinj M830, Impinj M850 | |
Memory | M830: EPC-128 bits; User-N/A; TID-96 bits M850: EPC-96 bits; User-32 bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 6 m to 10 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | CD/DVD Management,etc. |
