The 125kHz RFID Transponder is a low-frequency, contactless identification device designed for reliable short-range communication. Built with stable performance and high durability, it is ideal for access control, animal identification, industrial automation, and asset tracking applications.
Operating at 125kHz, this transponder offers excellent penetration through materials like plastic, wood, and even water, making it suitable for challenging environments. It features a unique ID for secure identification and is compatible with most standard LF RFID readers.
Key Features:
Operates at 125kHz low frequency
Excellent read performance through non-metallic materials
Unique identification code for secure data transmission
High durability and resistance to water, dust, and vibration
Compatible with a wide range of LF RFID readers
Available in various form factors (glass tube, coin tag, key fob, etc.)
The 125kHz RFID Transponder is a trusted choice for industries requiring cost-effective, durable, and secure RFID solutions.
Physical Specification | ||
|---|---|---|
Item | SRTPD326B | |
Tag size | Diameter 26 mm | |
Thickness | 3 mm | |
Material | PPS | |
Adhesive | N/A | |
Color | White, Black, etc. | |
Weight | 2.2 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2, ISO/IEC 15693, ISO/IEC 14443-A |
Operating Frequency | 902-928 MHz (US), 13.56 MHz (HF) | |
IC Type | NXP UCODE 9, NXP NTAG 213, NXP NTAG 215, NXP NTAG 216, NXP ICODE SLIX | |
Memory | UCODE 9: EPC-96 bits; User-N/A; TID-96 bits, NTAG 213: EEPROM-1440 bits (180 bytes) NTAG 215: EEPROM-4320 bits (540 bytes) NTAG 216: EEPROM-7392 bits (924 bytes), ICODE SLIX: EEPROM-1024 bits (128 bytes) | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 0-20 cm (Depend on tag performance and operating environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +120 °C / -40 °F to +248 °F |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
IP Rating | IP68 | |
Other Specification | Installation | Screw or backing adhesive |
Package Detail | 100pcs /bag or customized | |
Delivery Format | Single unit | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Logistics Tracking Management, Industrial Automation Process Control, Manufacturing Production Process Control, Warehouse Management, Oil and Gas Industry，etc. |
