The HF Transponder is a high-performance RFID solution designed to offer precise and efficient asset tracking, identification, and management in a wide range of industries. Operating at the 13.56 MHz frequency, this transponder ensures fast, reliable data transmission and is ideal for applications where short to mid-range communication is required. Whether used for inventory management, access control, or product authentication, the HF transponder provides accurate and secure data exchange.
Key Features:
13.56 MHz Frequency: Operating within the highly-regulated HF (High Frequency) range, the transponder provides consistent, stable performance with excellent read range (typically 10 cm to 1 meter) for accurate tracking in medium-sized operations.
Fast Data Transfer: Ensures fast and efficient data exchange between the tag and reader, allowing for quick and seamless integration into your asset tracking systems.
Reliable Performance: Known for its stability and resistance to interference from materials like water and metal, making it suitable for a variety of environments, including healthcare, libraries, retail, and logistics.
Compact & Versatile: Available in a variety of form factors, including adhesive labels, key fobs, and hard tags, the HF transponder is adaptable to many applications, from personal identification to product tracking.
Low Power Consumption: With low power requirements, the HF transponder is energy-efficient, offering long-term operation without the need for frequent replacements or maintenance.
Secure Data Transmission: Features built-in encryption and anti-collision protocols, ensuring the protection of sensitive data and enabling secure and private asset management.
Global Compatibility: Compatible with a wide range of HF RFID readers and systems, making it ideal for international applications and easy integration into existing infrastructure.
With the HF Transponder, you can ensure fast, secure, and reliable identification and tracking of assets and products, helping you streamline your operations, reduce errors, and enhance security.
Physical Specification | ||
|---|---|---|
Item | SRTPD12 | |
Tag size | Diameter 12 mm | |
Thickness | 4.5 mm | |
Material | PPS | |
Adhesive | 3M 300LSE | |
Color | White, Black, etc. | |
Weight | 2 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 15693 |
Operating Frequency | 13.56 MHz (HF) | |
IC Type | NXP ICODE SLIX | |
Memory | ICODE SLIX: EEPROM-1024 bits (128 bytes) | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 0-20 cm (Depend on tag performance and operating environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +120 °C / -40 °F to +248 °F |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
IP Rating | IP68 | |
Other Specification | Installation | Backing adhesive |
Package Detail | 100pcs /bag or customized | |
Delivery Format | Single unit | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Machine tool processing management,Mould management,Clamp management,Industrial line process control,etc. |
