SRU1209H3 (ALN-9613)

Enhance Item Tracking with Micro RFID Tags ALN-9613

Introducing the Enhance Item Tracking with Micro RFID Tags, the ultimate solution for precise and reliable item tracking. The ALN-9613 offers industry-leading EPC Gen 2 performance, ensuring that even the smallest items are monitored with unmatched accuracy. Its ultra-compact design makes it perfect for applications where space is at a premium and geometries are critical.

These Micro RFID Tags are specifically engineered for short read ranges, utilising advanced near-field coupling properties that excel on aqueous materials. Whether you’re managing inventory, tracking high-value assets, or ensuring quality control in manufacturing, these tags provide the perfect blend of reliability and performance.

Elevate your tracking capabilities with the micro RFID tags that adapt seamlessly to your needs, ensuring that no item goes untracked.

INQUIRY
INQUIRY
Datasheet
Access Control RFID Tags ISO/IEC 18000-6C
rfid access control bracelets
rfid access control cards
rfid access control wristbands
Physical Specification
Item
SRU1209H3 (ALN-9613)
Antenna size
12*9 mm
Tag size
15*12 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
860-960 MHz (Global), 902-928 MHz (US)
IC Type
Alien Higgs 3
Memory
Higgs 3: EPC-96(up to 480) bits; User-512 bits; TID-64 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
Up to 30 cm (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
Small items tracking, etc.
