The Fixed RFID Reader is a robust, high-performance device designed for continuous operation in dynamic, high-throughput environments. Whether it’s mounted over conveyor lines, entry gates, or dock doors, this reader provides dependable, real-time UHF tag scanning that powers automation, accuracy, and asset visibility.
Key Features:
Nonstop Tag Monitoring: Designed for 24/7 operation in fixed installations—ideal for inventory zones, inbound/outbound tracking, and automated workflows.
High Read Rates: Reads hundreds of UHF passive tags per second, powered by advanced anti-collision algorithms and EPC Gen2/ISO 18000-6C compliance.
Multi-Antenna Support: Connects to 2–4 (or more) external antennas for wide coverage and customizable read zones.
Industrial Durability: Rugged housing resists dust, vibration, and temperature fluctuations, ensuring reliable performance in harsh environments.
Flexible I/O & Connectivity: Integrates easily with PLCs, ERP systems, or middleware via Ethernet, RS232, GPIO, or Wi-Fi options.
Edge Intelligence Capable: Supports onboard filtering, tag event logic, and firmware customization for smarter, local processing.
Ideal Applications:
Warehouse dock door and pallet tracking
Conveyor belt item scanning
Factory WIP (Work-In-Progress) visibility
Access control for personnel or vehicles
Baggage and cargo management at airports
Built for precision and reliability, the Fixed RFID Reader turns every read zone into a smart, automated checkpoint—minimizing manual labor and maximizing real-time data flow across your operations.
Physical Specification | Dimension | 305*305*75 mm |
|---|---|---|
Material | ABS+ Die cast aluminum | |
Weight | 2 kg | |
Color | White | |
RFID Specificiation | Air Interface Protocol | EPC Global UHF Class 1 Gen 2, ISO 18000-6C |
Operating Frequency | US (902-928 MHz) EU (865-868 MHz) | |
RF Output Power | 0-33 dbm (Adjustable) | |
Built In Antenna | 9 dBi | |
Polarization | Circular | |
Reading Distance | 0-20 meters (Depend on tag performance and operating environment) | |
Special Functions | Support password/mask function | |
Working Mode | Active mode Answer mode Trigger mode | |
RSSI | Support | |
Data Communication | Standard Interface | RS232, Wiegand, Relay |
Optional Interface | TCP/IP, POE, WIFI, USB, TTL, RS485, etc. | |
Power Supply | 12V 2A | |
Reading Alarm | Buzzer | |
Indicator Light | Strip light (Red and Green) | |
Environment Specification | Mounting Methods | Screw, bracket |
IP Rating | IP 65 | |
Operating Temperature | -10°С to +55 °С | |
Storage Temperature | -20°С to +75°С | |
Other Specification | Package | 1 pc/box |
Accessories | Install bracet, power adapter, and plug (US, EU,CHN) | |
Personalization | Pre-print Logo / Barcode / QR / Series number, etc. | |
Final Inspection | 100% tested | |
Certification | CE Approved, RoHS Approved | |
Application | Parking lot managment, warehouse managment, etc. |
