SRH3722

Mifare Sticker

Upgrade your contactless projects with our versatile and high-performance Mifare Sticker. This sleek, adhesive sticker integrates the renowned Mifare chip technology, transforming any surface into a smart, secure node for your NFC (Near Field Communication) and RFID (Radio-Frequency Identification) applications.

This Mifare Sticker is built around the reliable Mifare Classic 1K (or NTAG213/215/216 – select based on your product) chip, offering a user-friendly and robust solution for a wide range of uses. Simply peel and stick it onto your personal item, device, or asset to enable seamless contactless interactions.

Key Features & Benefits:

  • Powered by Mifare Technology: At the heart of this sticker is the industry-standard Mifare chip, ensuring reliable, fast read/write operations and broad compatibility with a vast array of Mifare-enabled readers worldwide.

  • Ultra-Thin & Flexible Design: Crafted to be discreet and durable, this Mifare Sticker fits perfectly on phones, cards, tablets, notebooks, or equipment without adding bulk.

  • Strong Adhesive Backing: Features a permanent, high-tack adhesive that securely bonds to most clean, smooth surfaces, making your Mifare application a permanent or semi-permanent solution.

  • Multi-Purpose Application: This Mifare Sticker is your all-in-one tool for access control, secure data storage, inventory management, product authentication, and custom NFC triggers.

  • Easy to Program & Clone: Use any standard Mifare/NFC writer and compatible software to program, encode, or clone data onto this sticker. Ideal for prototyping, system migration, or creating backups.

  • Re-writable Memory: The embedded Mifare chip allows data to be updated, locked, or rewritten thousands of times, offering flexibility as your needs evolve.

Physical Specification
Item
SRH3722
Antenna size
37*22 mm
Tag size
40*25 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 14443-A
Operating Frequency
13.56 MHz (HF)
IC Type
NXP NTAG 213, NXP NTAG 215, NXP NTAG 216
Memory
NTAG 213: EEPROM-1440 bits (180 bytes)
NTAG 215: EEPROM-4320 bits (540 bytes)
NTAG 216: EEPROM-7392 bits (924 bytes)
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
6 m to 10 m (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
CD/DVD Management,etc.
