A Mifare Tag is a high-frequency, contactless smart card technology that revolutionizes how we manage access, payments, and identification. Built on robust encryption and reliable performance, each Mifare Tag serves as a key to a more efficient and secure ecosystem. Whether for physical access control, cashless vending, or public transportation, the versatility of a Mifare Tag is unmatched.
Key Features & Benefits:
Advanced Security & Encryption: Every Mifare Tag is equipped with sophisticated security mechanisms, including mutual authentication and sector-level encryption. This ensures your data and transactions are protected against unauthorized access and cloning.
High Performance & Reliability: Experience fast, reliable read/write operations. The Mifare Tag is designed for durability and consistent performance, even in high-traffic environments, ensuring seamless user experiences.
Universal Compatibility: Our Mifare Tag is fully compatible with the global ISO/IEC 14443 Type A standard. It works flawlessly with a vast range of existing Mifare-based readers and systems worldwide, making integration effortless.
Flexible Memory Options: Available in multiple memory configurations (e.g., 1K, 4K), the Mifare Tag offers ample space to store diverse data, from simple IDs to complex loyalty points and transaction logs.
Durable & Versatile Form Factors: More than just cards, the Mifare Tag technology is embedded in key fobs, stickers, and wristbands. Its durable construction withstands daily wear and tear, making it ideal for long-term use in any application.
Physical Specification | ||
|---|---|---|
Item | SRU4011 | |
Antenna size | 40*11 mm | |
Tag size | 43*14 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Qstar-7U | |
Memory | Qstar-7U: EPC-128(UP to 144) bits; User-128 bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 6 m to 10 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | CD/DVD Management,etc. |
