SRH5215

NFC Chip Manufacturers In China

As a trusted NFC chip manufacturer, we offer high-quality, customizable NFC chips designed to meet the unique needs of businesses across various industries. Our NFC chips are engineered for seamless integration into a wide range of applications, including asset tracking, mobile payments, contactless access control, product authentication, and digital marketing.

We provide flexible NFC solutions that can be tailored to your specific requirements, whether you need secure payment systems, enhanced customer engagement, or reliable data exchange in a wide variety of smart devices. Our chips are designed for fast, secure, and reliable communication with NFC-enabled devices, ensuring smooth interactions every time.

Key Benefits:

  • High-Quality NFC Chips: Manufactured with the latest technology for superior performance, reliability, and long-term durability.

  • Customizable Solutions: We work with you to design NFC chips that meet your specific needs, including custom memory, security features, and form factors.

  • Wide Range of Applications: Ideal for asset management, mobile payments, access control, product authentication, ticketing, and more.

  • Secure and Fast Communication: Our NFC chips ensure secure data exchange, supporting fast and reliable interactions with NFC-enabled smartphones and other devices.

  • Global Compatibility: Fully compatible with both Android and iOS devices, ensuring a wide reach for your NFC-powered applications.

Whether you’re integrating NFC technology into existing systems or developing new products, our NFC chips provide the reliability, security, and scalability you need. As your NFC chip manufacturer, we’re here to help you bring your ideas to life with high-performance, customizable solutions.

Physical Specification
Item
SRH5215
Antenna size
52*15 mm
Tag size
55*18 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 14443-A
Operating Frequency
13.56 MHz (NFC)
IC Type
NXP NTAG 213, NXP NTAG 215, NXP NTAG 216
Memory
NTAG 213: EEPROM-1440 bits (180 bytes)
NTAG 215: EEPROM-4320 bits (540 bytes)
NTAG 216: EEPROM-7392 bits (924 bytes)
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
5 cm to 20 cm (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
NFC tags for various NFC applications such as access control and mobile payments
