Unlock a world of convenience and innovation with our high-performance NTag213 sticker. This versatile and powerful NFC (Near Field Communication) tag is designed to bridge the physical and digital worlds effortlessly.
Product Highlights:
Advanced NTag213 Chip: At the heart of this sticker lies the reliable NTag213 integrated circuit from NXP Semiconductors. It offers 144 bytes of user memory, perfect for storing URLs, contact details, Wi-Fi credentials, or small commands.
Easy Programming & Compatibility: Simply tap with any NFC-enabled smartphone (Android or iOS) to read or write data. No app is required for basic reading, making it incredibly user-friendly.
Wide-Ranging Applications:
Smart Business Cards: Program your NTag213 sticker with your LinkedIn profile or contact details. A quick tap shares your information instantly.
Smart Home & IoT: Stick it near your door to automate tasks like turning on lights or connecting to Wi-Fi for guests.
Interactive Marketing: Embed it into posters, product packaging, or displays to link customers directly to websites, videos, or special offers.
Personal Automation: Use it to launch phone settings, apps, or routines (e.g., “Car Mode”) with a single tap.
Durable & Adhesive Design: The sticker form factor is thin, flexible, and features a strong adhesive backing. It can be discreetly applied to almost any smooth surface – notebooks, walls, devices, or cards.
Re-writable & Secure: Data on the NTag213 sticker can be rewritten thousands of times. It features built-in data protection mechanisms for controlled access.
Physical Specification | ||
|---|---|---|
Item | SRHD22 | |
Antenna size | D22 mm | |
Tag size | D25 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 14443-A |
Operating Frequency | 13.56 MHz (HF) | |
IC Type | NXP NTAG 213, NXP NTAG 215, NXP NTAG 216 | |
Memory | NTAG 213: EEPROM-1440 bits (180 bytes) NTAG 215: EEPROM-4320 bits (540 bytes) NTAG 216: EEPROM-7392 bits (924 bytes) | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 6 m to 10 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | CD/DVD Management,etc. |
