Tired of manual scanning, lost shipments, and inaccurate inventory counts? Step into the future of supply chain visibility with our advanced Pallet RFID solution.
What is Pallet RFID?
Our Pallet RFID system involves attaching a durable, high-performance RFID tag directly to your warehouse pallets. Unlike traditional barcodes, these tags can be read automatically, without line-of-sight, from a distance of several meters. This enables the simultaneous scanning of entire pallet loads as they move through key points in your supply chain.
Key Benefits of Our Pallet RFID Solution:
Unmatched Efficiency: Read dozens of pallets in seconds as they pass through dock doors, portals, or on forklifts. Eliminate manual, item-by-item scanning and dramatically speed up receiving, shipping, and cycle counts.
Perfect Inventory Accuracy: Gain real-time, 100% accurate visibility into your pallet-level inventory. Know the exact location and status of every pallet in your facility, reducing shrinkage and stockouts.
Enhanced Traceability & Compliance: Each Pallet RFID tag carries a unique identifier. Track the entire journey of a pallet from origin to destination, creating a complete audit trail perfect for compliance, recall management, and quality control.
Rugged & Reliable Design: Our Pallet RFID tags are engineered for the harsh industrial environment. They are built to withstand impacts, moisture, temperature extremes, and chemical exposure, ensuring long-term performance.
Seamless Integration: Our system is designed to integrate effortlessly with your existing Warehouse Management System (WMS), ERP, or other logistics software, providing immediate value without disrupting operations.
Physical Specification | ||
|---|---|---|
Item | SRUD30 | |
Antenna size | D30 mm | |
Tag size | D33 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Impinj M830, Impinj M850 | |
Memory | M830: EPC-128 bits; User-N/A; TID-96 bits M850: EPC-96 bits; User-32 bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 6 m to 10 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | CD/DVD Management,etc. |
