RFID adhesive tags offer a fast, flexible, and cost-effective way to bring smart identification and tracking to nearly any asset or surface. With a peel-and-stick backing and ultra-slim profile, these tags combine high-performance RFID functionality with easy, tool-free application.
Typically made with paper, PET, or synthetic label materials, adhesive RFID tags can be customized with logos, barcodes, or human-readable information. They’re commonly used in retail, logistics, warehousing, manufacturing, and healthcare to tag cartons, IT devices, files, equipment, or even metal assets when paired with foam spacers or metal-on support layers.
Easy Application: Simple peel-and-stick design—no screws, rivets, or tools needed
Slim & Flexible: Ultra-thin labels that conform to flat or slightly curved surfaces
Custom Printable: Optional printing for barcodes, branding, or serial numbers
Available in Multiple Frequencies: UHF (860–960 MHz), HF (13.56 MHz), or NFC for various read ranges
Surface Compatibility: Designed for cardboard, plastic, glass, and—with special designs—even metal
Cost-Effective: Ideal for high-volume deployment at low per-unit cost
Strong Adhesives: Industrial-grade bonding for permanent or semi-permanent applications
Physical Specification | ||
|---|---|---|
Item | SRU7014 | |
Antenna size | 70*14 mm | |
Tag size | 73*17 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Impinj M730, Impinj M750, Impinj M770, Impinj M775, Impinj M780, Impinj M781 | |
Memory | M730: EPC-128 bits; User-N/A; TID-96 bits M750: EPC-96 bits; User-32 bits; TID-96 bits M770: EPC-128 bits; User-32 bits; TID-96 bits M775: EPC-128 bits; User-32 bits; TID-96 bits M780: EPC-496 bits; User-128 bits; TID-96 bits M781: EPC-128 bits; User-512 bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 4 m to 12 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | For apparel management, etc. |
