Our Advanced Tamper-Proof RFID Tags represent the pinnacle of security and asset management technology. Engineered for environments where integrity is non-negotiable, these tags are designed to permanently and visibly indicate any attempted tampering, removal, or unauthorized access. Ideal for high-security assets, confidential documents, retail electronics, pharmaceuticals, and access control systems, they provide an irreversible alert, ensuring your valuable items remain tracked and protected.
Key Features & Benefits:
Irreversible Tamper Evidence: The core of our product is its tamper-proof RFID tags mechanism. Constructed with a fragile destructible substrate or a special adhesive layer, any attempt to remove the tag causes it to delaminate, break apart, or display a clear “VOID” pattern. This physical alteration is permanent and easily visible, providing immediate visual and functional evidence of compromise.
Instant Functional Disablement: Upon tampering, the embedded RFID inlay (chip and antenna) is intentionally damaged or detached, rendering the tag permanently unreadable. This ensures that a stolen or tampered-with item cannot be re-tagged and reintroduced into your secure system unnoticed.
High-Performance RFID Functionality: Before any tamper event, these tags offer reliable, long-range read/write capabilities. Compatible with UHF (RAIN RFID) or HF (NFC) frequencies, they enable fast inventory scans, robust asset tracking, and seamless integration with your existing RFID infrastructure.
Durable & Versatile Design: Built to withstand harsh environmental conditions—including moisture, dust, and temperature fluctuations—during normal use. Available in various sizes, form factors, and adhesive strengths to adhere securely to multiple surfaces like metal, plastic, glass, and paper.
Enhanced Operational Security & Accountability: By deploying our tamper-proof RFID tags, you create a powerful deterrent against theft and fraud. They automate security audits, provide a clear chain of custody, and significantly reduce losses, improving overall operational efficiency and accountability.
Physical Specification | ||
|---|---|---|
Item | SRU9610 | |
Antenna size | 44.45*10.325 mm | |
Tag size | 48*14 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Alien Higgs 9 | |
Memory | Higgs 9: EPC-96(up to 496) bits; User- up to 688 bits; TID-48 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 6 m to 10 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | CD/DVD Management,etc. |
