The RFID Asset Management System is a cutting-edge solution designed to track, monitor, and manage assets with precision and efficiency. By leveraging RFID technology, this system provides real-time visibility and control over assets, helping businesses streamline operations, reduce losses, and optimize resource utilization. Whether you’re managing office equipment, machinery, or inventory, RFID Asset Management ensures accurate tracking and seamless integration into your workflow.
Our RFID Asset Management System revolutionizes the way businesses manage their resources. By automating tracking processes, enhancing asset visibility, and reducing operational inefficiencies, this solution helps businesses save time, reduce costs, and improve overall productivity.
Contact us today to learn how RFID Asset Management can transform your operations and maximize asset value!
Physical Specification | ||
|---|---|---|
Item | SRU2207 | |
Antenna size | 22*7 mm | |
Tag size | 25*10 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Impinj Monza R6, Impinj Monza R6-P | |
Memory | Monza R6: EPC-96 bits; User-N/A; TID-96 bits Monza R6-P: EPC-128(96) bits; User-32(64) bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 1 m to 8 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Used for apparel retail, jewelry, packaging boxes, logistics, medical, books, etc. |
