SRUJ61

RFID Circle Sticker

Introducing the RFID Circle Sticker, a versatile and innovative solution designed to simplify asset tracking and identification across a wide range of industries. This compact, circular RFID sticker combines cutting-edge technology with a user-friendly design, making it an essential tool for businesses looking to enhance efficiency, accuracy, and visibility in their operations.

Key Features:

  • Compact and Flexible Design: The RFID Circle Sticker is designed in a sleek, circular form factor, allowing it to be easily applied to curved or irregular surfaces without compromising performance.
  • High-Performance UHF RFID Technology: Equipped with ultra-high frequency (UHF) RFID capabilities, this sticker offers long read ranges and fast data transmission, ensuring reliable tracking even in demanding environments.
  • Adhesive Backing: Featuring a strong, durable adhesive, the sticker can be securely attached to a variety of materials, including plastic, metal, glass, and more, making it suitable for diverse applications.
  • Cost-Effective Solution: As a lightweight and affordable RFID option, the RFID Circle Sticker provides exceptional value without sacrificing performance.
  • Global Compliance: Compliant with international RFID standards, ensuring seamless integration into existing systems worldwide.
INQUIRY
INQUIRY
Datasheet
Jewelry Tag Identification
rfid tag for jewellery
jewelry tag identification
rfid tags for jewelry
Physical Specification
Item
SRUJ61
Antenna size
D12 mm
Tag size
15 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
860-960 MHz (Global)
IC Type
Impinj Monza R6, Impinj Monza R6-P
Memory
Monza R6: EPC-96 bits; User-N/A; TID-96 bits
Monza R6-P: EPC-128(96) bits; User-32(64) bits; TID-96 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
0.2 m to 3 m (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
Used for medicines, jewelry, etc.

Related Products

NFC clothing tags​

NFC clothing tags​

Custom Labels For Clothing

Custom Labels For Clothing

RFID Logistics Tracking​
