SRU7014

Smart Track RFID

Introducing Smart Track RFID – the next-generation solution that transforms how businesses monitor, manage, and optimize their physical assets. More than just a tracking tool, Smart Track RFID is a comprehensive, cloud-connected platform that delivers real-time intelligence across your entire operation.

What is Smart Track RFID?
Smart Track RFID is an integrated hardware and software ecosystem designed for precision tracking. It combines high-performance RFID tags, strategically placed smart readers, and a powerful AI-driven dashboard to provide unparalleled visibility of inventory, equipment, and shipments from source to destination.

Core Capabilities & Benefits:

  • Real-Time, Automated Visibility: Move beyond manual scans. The Smart Track RFID system automatically captures the location and movement of tagged items as they pass through key checkpoints—warehouse gates, production zones, or retail floors—updating your dashboard instantly.

  • Pinpoint Accuracy & Analytics: Don’t just track; understand. Our platform turns raw movement data into actionable insights. Identify bottlenecks, optimize workflow paths, and prevent stockouts or overstock with predictive analytics powered by Smart Track RFID intelligence.

  • End-to-End Supply Chain Clarity: Gain a single, unified view of your assets from manufacturing to delivery. Enhance supply chain transparency, reduce loss, and improve accountability with the end-to-end traceability offered by Smart Track RFID.

  • Scalable & Flexible Deployment: Whether you need to monitor a single warehouse or a global distribution network, Smart Track RFID scales with you. Our modular system supports everything from passive UHF tags for pallet-level tracking to battery-assisted tags for high-value shipments.

  • Seamless System Integration: Smart Track RFID is built to connect. It integrates effortlessly with your existing ERP, WMS, or inventory management software, ensuring data flows smoothly into your core business systems.

Physical Specification
Item
SRU7014
Antenna size
70*14 mm
Tag size
73*17 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
860-960 MHz (Global)
IC Type
Kiloway KX2005X-S
Memory
KX2005X-S: EPC-128 bits; User-N/A bits; TID-96(up to 192) bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
6 m to 10 m (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
CD/DVD Management,etc.
