Elevate your clothing management with our RFID M730 MINIWEB, a cutting-edge solution tailored for the fashion industry. Perfectly designed for clothing applications, these smart RFID tags seamlessly integrate into your garments, revolutionizing inventory control, and supply chain visibility. Enhance the retail experience with precise tracking, reduce stockouts, and bolster anti-theft measures. Our RFID M730 MINIWEB tags redefine the standards of efficiency and security in clothing management. Step into the future of fashion with technology that empowers your brand. Explore the potential of RFID innovation for unparalleled control, accuracy, and success in the dynamic world of apparel.
Physical Specification | ||
|---|---|---|
Item | SRU4216 | |
Antenna size | 42*16 mm | |
Tag size | 45*19 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Impinj M730, Impinj M750, Impinj M770, Impinj M775, Impinj M780, Impinj M781 | |
Memory | M730: EPC-128 bits; User-N/A; TID-96 bits M750: EPC-96 bits; User-32 bits; TID-96 bits M770: EPC-128 bits; User-32 bits; TID-96 bits M775: EPC-128 bits; User-32 bits; TID-96 bits M780: EPC-496 bits; User-128 bits; TID-96 bits M781: EPC-128 bits; User-512 bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 5 m to 12 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | For apparel management, etc. |
