SRU4015

RFID Monza R6-P MINIWEB Sticker For Apparel

The RFID Monza R6-P MINIWEB Sticker is a cutting-edge solution designed for the apparel industry, offering superior performance and efficiency in tracking and inventory management. With its compact size and advanced technology, it seamlessly integrates into retail, logistics, and supply chain operations.

This RFID sticker is perfect for streamlining apparel management, enhancing operational efficiency, and improving customer satisfaction through accurate stock monitoring and seamless checkout processes.

INQUIRY
INQUIRY
Datasheet
RFID Monza R6-P MINIWEB Sticker For Apparel
clothing label​
clothing care labels​
clothes labels
Physical Specification
Item
SRU4015
Antenna size
40*15 mm
Tag size
44*19 mm
Thickness
11–18 mils / 279–463 microns
Material
Paper / PP / PET or customized
Adhesive
Solvent free permanent acrylic adhesive
Color
White, Transparent, etc.
Weight
0.01 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
860-960 MHz (Global)
IC Type
Impinj Monza R6, Impinj Monza R6-P
Memory
Monza R6: EPC-96 bits; User-N/A; TID-96 bits
Monza R6-P: EPC-128(96) bits; User-32(64) bits; TID-96 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
2 m to 8 m (Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-40 °C to +85 °C / -40 °F to +185 °F
Operating Humidity
20% to 60% RH
Recommended Storage
+25°C / 77°F, 40% RH
Bend Diameter
> 1.97” / 50 mm
Pressure
< 5N/mm2
Drop Resistance
Per ASTM D5276
Shelf Life
2 years at +25°C / +77°F, 40% RH
ESD Voltag Immunity
±2 kV peak HBM
Other Specification
Package Detail
3000 pcs/reel, vacuumed in ESD bag or customized
Core Size
76.2 mm / 3 in, etc.
Delivery Format
On reel for dry inlay, wet inlay, label
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
For apparel retail management, etc.
