Our high-performance RFID On-Metal Hard Tags are designed for demanding industrial and outdoor applications, offering ultra-long read ranges of up to 11 meters (depending on the reader setup). Operating in the 902-928 MHz (US) or 865-868 MHz (EU) frequency ranges, these rugged tags are powered by the Alien Higgs-3 IC, ensuring industry-leading reliability and data integrity.
✔ Built for Harsh Environments – IP68-rated for complete protection against dust, water, and contaminants, making them ideal for outdoor or industrial use.
✔ Optimized for Metal Surfaces – Specially engineered to maintain performance when mounted directly on metal.
✔ Versatile Attachment Options – Can be secured using high-strength adhesives, a rivet hole, or a cable tie for flexible installation.
✔ Extended Read Range – Leverages UHF RFID technology for long-distance scanning, improving efficiency in asset tracking, logistics, and inventory management.
Ideal for: Tyre labeling, heavy machinery tracking, warehouse assets, construction equipment, and more.
Physical Specification | ||
|---|---|---|
Item | SRUHT069 | |
Tag size | 69*23 mm | |
Thickness | 7 mm | |
Material | ABS, PC | |
Adhesive | High tack adhesive with excellent adhesion / 3M (optional) | |
Color | White, etc. | |
Weight | 10.8 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | NXP UCODE 8 | |
Memory | UCODE 8: EPC-128 bits; User-N/A; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | Up to 11.0 meters,US (902-928 MHZ) ;Up to 10.0 meters,EU (865-868 MHZ) | |
Feature | Workable on metal surface | |
Environmental Specification | Operating Temperature | -25 °C to +85 °C / -13 °F to +185 °F |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
IP Rating | IP68 | |
Other Specification | Installation | Screw or backing adhesive |
Package Detail | 50 pcs/bag or customized | |
Delivery Format | Single unit | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Suitable for metal surfaces, harsh outdoor environments and exposure to water and contaminants. It can be attached using high performance adhesives, through rivet holes, or using cable ties. |
