Elevate your cosmetics packaging with our UHF RFID Anti-Metal Labels, a groundbreaking solution designed for precision and security. Tailored specifically for cosmetics packaging, these RFID labels seamlessly integrate into your products, offering advanced anti-metal capabilities for reliable tracking and traceability. Enhance supply chain visibility, prevent counterfeiting, and optimize inventory management with real-time data insights. Our UHF RFID Anti-Metal Labels redefine the standards of efficiency and authenticity, providing an essential tool for the cosmetics industry. Step into the future of cosmetics packaging with technology that ensures precision, control, and trust. Explore the potential of intelligent tracking and protection with our state-of-the-art RFID solutions, perfectly crafted for cosmetics packaging applications.
Physical Specification | ||
|---|---|---|
Item | SRUFLX6406 | |
Tag size | 64*6 mm | |
Thickness | 1.0 mm | |
Material | White PET | |
Adhesive | High tack adhesive with excellent adhesion / 3M (optional) | |
Color | White, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 902-928 MHz (US), 865-868 MHz (EU) | |
IC Type | NXP UCODE 8, NXP UCODE 9 | |
Memory | UCODE 9: EPC-96 bits; User-N/A; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range (Fixed reader) | US: On metal up to 4.0 m, On liquid up to 4.5 m EU: On metal up to 3.5 m, On liquid up to 6.5 m | |
Read Range (Handheld reader) | US: On metal up to 2.0 m, On liquid up to 2.5 m EU: On metal up to 1.5 m, On liquid up to 4.5 m | |
Feature | Workable on metallic curved surface | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 1 years at +20°C / +68°F, 50% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Vibration | MIL-STD-810G | |
IP Rating | IP68, tested for 5 hours in 1m deep water | |
Other Specification | Package Detail | 500 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for label | |
Printer Compatibility | SATO CL4NX, Zebra ZT410 Silverline, Postek TX3r, etc. | |
Installation | Clean and dry the surface before the mounting | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Logistic management, Warehouse management, Apparel management, etc. |
