Introducing our high-performance 860-960MHz UHF RFID Cable Tie Tag, the ultimate solution for secure and intelligent asset management. This innovative tag seamlessly combines the robust physical security of a standard cable tie with the advanced tracking capabilities of UHF RFID technology. Designed for durability and long-range reading, it is the perfect tool for a wide array of industrial and logistical applications.
Dual-Function Design: This product is not just a tag; it’s a fully functional, self-locking nylon cable tie. It physically secures your assets while simultaneously providing a unique digital identity for each item.
Global UHF Frequency Compatibility: Operating within the 860-960MHz UHF RFID band, this tag is compliant with global standards (EPC Global C1G2, ISO 18000-6C), making it suitable for use anywhere in the world.
Long Read Range: Engineered for excellent performance, this tag offers a superior read range, allowing for fast and accurate batch scanning of multiple items without direct line-of-sight. This dramatically improves inventory efficiency and reduces labor costs.
Exceptional Durability: The tag body is made from high-strength engineering plastic (PP/PA66), offering excellent resistance to water, dust, chemicals, and impact. It is built to withstand harsh environmental conditions, both indoors and outdoors.
Easy to Install & Reusable (Optional): Installation is quick and simple—just thread, tighten, and lock. Certain models are designed with a releasable head for temporary applications, allowing for reuse and repositioning.
Customizable Data & Encoding: Each 860-960MHz UHF RFID Cable Tie Tag comes with a unique, factory-locked TID and a user-accessible EPC memory bank, allowing you to encode custom asset information for easy identification and tracking.
Physical Specification | ||
|---|---|---|
Item | SRSEAL4285 | |
Tag size | 42*85 mm | |
Thickness | 3 mm | |
Material | ABS | |
Color | White, Black, Yellow, Green, Blue, Red, Orange, etc. | |
Weight | 15.4 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2, ISO/IEC 15693, ISO/IEC 14443-A |
Operating Frequency | 860-960 MHz (Global), 13.56 MHz (HF) | |
IC Type | NXP NTAG 213, NXP ICODE SLIX | |
Memory | NTAG 213: EEPROM-1440 bits (180 bytes) NTAG 215: EEPROM-4320 bits (540 bytes) NTAG 216: EEPROM-7392 bits (924 bytes), ICODE SLIX: EEPROM-1024 bits (128 bytes) | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 0.1 cm to 5 cm(Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -35 °C to +85 °C / -31 °F to +185 °F |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
IP Rating | IP65 | |
Other Specification | Installation | Self-locking |
Package Detail | 50 pcs/bag or customized | |
Delivery Format | Single unit | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | For goods signs, logistics and transportation facilities, security inspections, petrochemical facilities, rail transit facilities, mobile communication facilities, anti-counterfeiting identification, biometric identification, security inspection facilities, power asset equipment management, etc |
