SRU9962

ALN-9962 Short Higgs 9 Clear Wet Inlay

The ALN-9962 Short Higgs 9 Clear Wet Inlay is a game-changer in RFID technology, designed to deliver unmatched efficiency and precision. Tailored for optimal performance, this clear wet inlay seamlessly integrates into diverse applications, ensuring reliability and accuracy in every use case.Elevate your asset tracking, inventory management, and logistics with the advanced RFID capabilities of the ALN-9962. This innovative solution provides real-time visibility, significantly reducing errors and optimizing operational processes.

Why Choose ALN-9962 Short Higgs 9 Clear Wet Inlay?

Our RFID inlay offers a secure, user-friendly, and cost-effective solution for a wide range of applications. With advanced technology, durable design, and seamless integration, the ALN-9962 empowers businesses to enhance control and accuracy in their operations.

The ALN-9962 Short Higgs 9 Clear Wet Inlay is perfect for:

Asset Tracking: Ensure accurate and efficient tracking of assets across multiple locations.
Inventory Management: Simplify inventory control with real-time updates and precise data.
Logistics: Enhance logistics operations with reliable and efficient tracking solutions.
Access Control: Manage secure access to restricted areas in corporate offices, data centers, and industrial facilities.

By integrating the ALN-9962 into your system, you can:

Enhance Security: Reliable and tamper-proof identification for sensitive areas.
Streamline Operations: Fast and accurate scanning for improved efficiency.
Reduce Costs: Minimize manual checks and errors, lowering operational expenses.

The ALN-9962 Short Higgs 9 Clear Wet Inlay offers a clear advantage in RFID technology, providing businesses with heightened control and accuracy. This state-of-the-art solution is designed to meet the evolving demands of modern industries, ensuring you stay ahead of the competition.

INQUIRY

Datasheet


Physical Specification
	Item	SRU9962
	Antenna size	70*17 mm
	Tag size	74*20 mm
	Thickness	11–18 mils / 279–463 microns
	Material	Paper / PP / PET or customized
	Adhesive	Solvent free permanent acrylic adhesive
	Color	White, Transparent, etc.
	Weight	0.01 g
RFID Specification	Air Interface Protocol	ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
	Operating Frequency	860-960 MHz (Global)
	IC Type	Alien Higgs 9
	Memory	Higgs 9: EPC-96(up to 496) bits; User- up to 688 bits; TID-48 bits
	Write Endurance	100,000 cycles
	Data Retention	Up to 20 years
	Read Range	5 m to 9 m (Depend on reader and environment)
	Feature	Bulk identification
Environmental Specification	Operating Temperature	-40 °C to +85 °C / -40 °F to +185 °F
	Operating Humidity	20% to 60% RH
	Recommended Storage	+25°C / 77°F, 40% RH
	Bend Diameter	1.97” / 50 mm
	Pressure	< 5N/mm2
	Drop Resistance	Per ASTM D5276
	Shelf Life	2 years at +25°C / +77°F, 40% RH
	ESD Voltag Immunity	±2 kV peak HBM
Other Specification	Package Detail	3000 pcs/reel, vacuumed in ESD bag or customized
	Core Size	76.2 mm / 3 in, etc.
	Delivery Format	On reel for dry inlay, wet inlay, label
	Samples Policy	For free if stock available
	Personalization	Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
	Final Inspection	100% tested, defective tags marked
	Certification	CE Approved, RoHs Approved, etc.
	Application	Logistic management, Warehouse management, Apparel management, etc.
