Transform the way you manage and interact with apparel using NFC Clothing Tags. These advanced tags integrate Near Field Communication (NFC) technology, offering innovative solutions for inventory management, brand engagement, and customer experiences.
Perfect for fashion brands, retailers, and manufacturers looking to combine technology with clothing, NFC Clothing Tags enhance brand value while offering practical benefits for both businesses and consumers.
Physical Specification | ||
|---|---|---|
Item | SRH3722 | |
Antenna size | 37*22 mm | |
Tag size | 40*25 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 14443-A |
Operating Frequency | 13.56 MHz (NFC) | |
IC Type | NXP NTAG 213, NXP NTAG 215, NXP NTAG 216 | |
Memory | NTAG 213: EEPROM-1440 bits (180 bytes) NTAG 215: EEPROM-4320 bits (540 bytes) NTAG 216: EEPROM-7392 bits (924 bytes) | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 0.1 m to 0.3 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Used for various NFC applications such as access control and mobile payments, etc. |
