A custom RFID cable tie tag combines the versatility of RFID technology with the flexibility of cable ties, providing a unique solution for secure and efficient asset tracking. Tailored to meet specific industry needs, these RFID tags are ideal for applications in telecom, utilities, logistics, and industrial environments, where tagging irregular objects like cables, pipes, and equipment is essential.
With custom options for size, color, chip type, and durability, these tags offer robust tracking capabilities while allowing you to align the design to your branding or operational requirements.
Custom Features:
Chip Type: Select from UHF (860–960 MHz), HF (13.56 MHz), or NFC, based on range and system compatibility
Durability: Choose materials such as nylon, polypropylene, or UV-resistant plastics for outdoor and harsh conditions
Tag Size & Shape: Custom lengths and widths to fit specific objects, such as cables, pipes, or irregularly shaped tools
Color & Branding: Customize the color and add logos, serial numbers, or barcodes for easy identification
Mounting: Standard or custom cable tie designs that fit your specific application, such as long ties for larger bundles or compact ones for smaller cables
Security: Tamper-evident designs or one-time use features for enhanced security and asset protection
Read Range: Tailored for various environments, from 1 meter (HF) to 10 meters (UHF)
Physical Specification | ||
|---|---|---|
Item | SRUPCB5213 | |
Tag size | 53*13 mm | |
Thickness | 3.5 mm | |
Material | PCB | |
Adhesive | 3M 300LSE | |
Color | White, Black, etc. | |
Weight | 1.2 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 902-928 MHz (US), 865-868 MHz (EU) | |
IC Type | NXP UCODE 8, Alien Higgs 3, Alien Higgs 9 | |
Memory | UCODE 8: EPC-128 bits; User-N/A; TID-96 bits , Higgs 3: EPC-96(up to 480) bits; User-512 bits; TID-64 bits, Higgs 9: EPC-96(up to 496) bits; User- up to 688 bits; TID-48 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range (Fixed Reader) | 530 cm, (US) 902-928MHz, On Metal 520 cm, (EU) 865-868MHz, On Metal | |
Read Range Handheld Reader | 280 cm, (US) 902-928MHz, On Metal 270 cm, (EU) 865-868MHz, On Metal | |
Feature | Workable on metal surface | |
Environmental Specification | Operating Temperature | -40 °C to +150 °C / -40 °F to +302 °F |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
IP Rating | IP68 | |
Other Specification | Installation | Screw or backing adhesive |
Package Detail | 50 pcs/ESD bag or customized | |
Delivery Format | Single unit | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested | |
Certification | CE Approved, RoHs Approved, Reach Approved, etc. | |
Application | Military Armories Tracking, Police Stations & Tactical Units Management, Private Security Firms Equipment, etc. |
