SRUPCBD10

Etiqueta RFID Para Metal

The RFID Tag for Metal is specifically engineered to overcome the signal interference typically caused by metallic surfaces. Unlike standard RFID tags, these are equipped with ferrite or foam insulation layers that enable stable and accurate performance when affixed directly to metal objects.

Whether you’re tagging steel containers, power tools, machinery, or IT assets, this tag provides consistent read performance in the most metal-dense environments.

Key Features:

  • Metal-Safe Design: Built-in shielding or spacers prevent detuning of the RFID antenna, ensuring high read reliability.

  • Durable Construction: Resistant to abrasion, chemicals, temperature, and UV exposure—perfect for industrial use.

  • Compact & Flexible: Available in both rugged hard tags and printable label formats for diverse applications.

  • Custom Mounting: Adhesive, magnetic, or screw-in options for permanent or temporary installations.

  • Frequency Options: Compatible with UHF (860–960 MHz), HF (13.56 MHz), and NFC standards.

Physical Specification
Item
SRUPCBD10
Tag size
D10 mm
Thickness
3.7 mm
Material
PCB
Adhesive
3M 300LSE
Color
White, Black, etc.
Weight
0.5
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
902-928 MHz (US), 865-868 MHz (EU)
IC Type
NXP UCODE 8, Alien Higgs 3, Alien Higgs 9
Memory
UCODE 8: EPC-128 bits; User-N/A; TID-96 bits
, Higgs 3: EPC-96(up to 480) bits; User-512 bits; TID-64 bits, Higgs 9: EPC-96(up to 496) bits; User- up to 688 bits; TID-48 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
(Fixed Reader)
150 cm, (US) 902-928MHz, On Metal
130 cm, (EU) 865-868MHz, On Metal
Read Range
Handheld Reader
100 cm, (US) 902-928MHz, On Metal
95 cm, (EU) 865-868MHz, On Metal
Feature
Workable on metal surface
Environmental Specification
Operating Temperature
-40 °C to +150 °C / -40 °F to +302 °F
Recommended Storage
+25°C / 77°F, 40% RH
Shelf Life
2 years at +25°C / +77°F, 40% RH
IP Rating
IP68
Other Specification
Installation
Screw or backing adhesive
Package Detail
50 pcs/ESD bag or customized
Delivery Format
Single unit
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested
Certification
CE Approved, RoHs Approved, Reach Approved, etc.
Application
Tooling Tracking, IT Asset Management, Medical Equipment, etc.
