Our Medical Device RFID Chips are designed to ensure accurate tracking, secure inventory management, and full traceability of medical devices throughout the supply chain. These high-performance chips are ideal for the healthcare industry, offering enhanced security and compliance with industry regulations, including patient safety and device tracking.
Perfect for manufacturers, hospitals, and healthcare providers, our Medical Device RFID Chips offer a reliable, scalable solution for tracking, managing, and ensuring the safety of medical devices, helping to enhance operational efficiency and regulatory compliance.
Physical Specification | ||
|---|---|---|
Item | SRUJ41 | |
Antenna size | D12 mm | |
Tag size | D15 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Impinj Monza 4E, Impinj Monza 4D, Impinj Monza 4i, Impinj Monza 4QT | |
Memory | Monza 4QT: EPC-512 bits; User-128 bits; TID-96 bits Monza 4E: EPC-128 bits; User-496 bits; TID-96 bits Monza 4D: EPC-32 bits; User-128 bits; TID-96 bits Monza 4i: EPC-480 bits; User-512 bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 0.2 m to 2 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Used for medicines, jewelry, etc. |
