Introducing the Omni ID Tag – the revolutionary, all-in-one identification platform designed to seamlessly integrate into any ecosystem. The Omni ID Tag is more than just a label; it’s a powerful smart asset management tool built for the interconnected world.
What is the Omni ID Tag?
The Omni ID Tag is a versatile, durable, and multi-technology identification badge. It combines multiple data capture methods into a single, ruggedized form factor. Whether you need QR, NFC, RFID (UHF/HF), or BLE connectivity, the Omni ID Tag delivers. This universal compatibility ensures your assets, inventory, or personnel are always identifiable and traceable, regardless of the reading system in use.
Key Features & Benefits:
Universal Interoperability: The core innovation of the Omni ID Tag is its ability to work with a vast array of scanners and smartphones. Break free from vendor lock-in and siloed systems.
Unmatched Durability: Engineered for harsh environments, the Omni ID Tag is resistant to water, chemicals, extreme temperatures, and physical abrasion. It’s built to last, ensuring your identification data remains accessible.
High-Capacity Data Storage: Embed extensive information directly onto the tag. From serial numbers and maintenance history to URLs and encrypted credentials, the Omni ID Tag carries the data you need.
Enhanced Security: With advanced encryption and unique identifiers, the Omni ID Tag prevents counterfeiting and unauthorized access, securing your supply chain and access points.
Easy Integration & Deployment: The Omni ID Tag is designed for plug-and-play functionality. Quickly deploy it across your operations for inventory control, logistics tracking, tool management, or secure access without overhauling your existing infrastructure.
Physical Specification | ||
|---|---|---|
Item | SRU3015 | |
Antenna size | 30*15 mm | |
Tag size | 33*18 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | NXP UCODE 8, NXP UCODE 9 | |
Memory | UCODE 9: EPC-96 bits; User-N/A; TID-96 bits UCODE 8: EPC-128 bits; User-N/A; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 6 m to 10 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | CD/DVD Management,etc. |
