Tired of unreliable seals and manual inventory checks? Introducing the Guardian UHF RFID Seal Tie Tag, the next-generation solution that combines robust physical security with the power of digital tracking. This isn’t just a seal; it’s an intelligent sentinel for your assets, containers, and high-value goods.
High-Performance UHF RFID:
Effortless Bulk Scanning: Read hundreds of tags simultaneously from a distance of up to 10 meters (30+ feet), eliminating the need for line-of-sight or manual handling.
Global Compliance: Operates on the UHF frequency (860-960MHz), making it ideal for global supply chains and logistics.
Unique Digital Identity: Each tag contains a unique, tamper-evident EPC number, turning every physical item into a trackable digital asset.
Superior Physical Security:
One-Time Use & Tamper-Proof: Once locked, the tie cannot be removed without visibly breaking the housing or the strap. Any attempt at tampering is immediately evident, ensuring the integrity of your shipment or asset.
Rugged & Durable Construction: Made from reinforced ABS plastic or Nylon, our seal tag is built to withstand harsh environments, including exposure to moisture, dust, and impact.
Designed for Efficiency & Versatility:
Easy to Apply & Lock: The simple tie-wrap design allows for quick and easy application by hand, securing instantly.
Customizable Options: Available with custom-printed logos, sequential barcodes, or QR codes to integrate seamlessly into your existing workflow.
Wide Range of Applications: The perfect all-in-one solution for securing and tracking shipping containers, airline galley carts, retail cages, warehouse pallets, utility meters, and evidence bags.
Physical Specification | ||
|---|---|---|
Item | SRSEAL7928 | |
Tag size | 79*28 mm | |
Thickness | 4 mm | |
Material | ABS | |
Color | White, Black, Yellow, Green, Blue, Red, Orange, etc. | |
Weight | 11.1 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2, ISO/IEC 15693, ISO/IEC 14443-A |
Operating Frequency | 860-960 MHz (Global), 13.56 MHz (HF) | |
IC Type | NXP NTAG 213, NXP ICODE SLIX | |
Memory | NTAG 213: EEPROM-1440 bits (180 bytes) NTAG 215: EEPROM-4320 bits (540 bytes) NTAG 216: EEPROM-7392 bits (924 bytes), ICODE SLIX: EEPROM-1024 bits (128 bytes) | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 0.1 cm to 5 cm(Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -35 °C to +85 °C / -31 °F to +185 °F |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
IP Rating | IP65 | |
Other Specification | Installation | Self-locking |
Package Detail | 50 pcs/bag or customized | |
Delivery Format | Single unit | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | For goods signs, logistics and transportation facilities, security inspections, petrochemical facilities, rail transit facilities, mobile communication facilities, anti-counterfeiting identification, biometric identification, security inspection facilities, power asset equipment management, etc |
