SRSEAL4035

RFID Cable Tie Tag Self-locking

This innovative product integrates a high-performance UHF RFID inlay directly into a heavy-duty, self-locking nylon cable tie. It is designed for applications where you need not only to identify an item digitally but also to physically secure or tag it permanently. Once locked, it cannot be removed without being cut, providing tamper-evident security.


Key Features & Benefits:

  • Dual-Function Design: Acts as both a secure physical fastener and a powerful digital data carrier. Eliminates the need for separate tags and ties, saving time and reducing application costs.

  • High-Performance RFID Technology: Features a UHF RFID chip (e.g., Impinj Monza R6, Alien Higgs) with excellent read range and consistent performance. Compatible with global EPC Gen2 UHF standards for seamless integration with your existing systems.

  • Tamper-Evident & Self-Locking: The one-way locking mechanism ensures a tight and permanent seal. Any attempt to remove it requires cutting the tie, providing a clear visual indicator of tampering—ideal for security seals, calibration tags, and maintenance logs.

  • Durable & Resilient: Made from rugged Nylon 66 material, these ties are resistant to abrasion, chemicals, moisture, and UV exposure. They perform reliably in harsh indoor and outdoor environments, from industrial warehouses to construction sites.

  • Easy Encoding & Application: Simply use a standard RFID printer encoder to write data and print visible information (barcodes, text, logos) onto the flat surface. The self-locking mechanism is easy to apply by hand or with a tensioning tool for a consistent, secure fit.

  • Versatile Sizes & Colors: Available in various lengths (e.g., 300mm, 400mm) and multiple colors (White, Black, Yellow, etc.) to support different color-coding systems and application needs.

Physical Specification
Item
SRSEAL4035
Tag size
40*35 mm
Thickness
5 mm
Material
ABS
Color
White, Black, Yellow, Green, Blue, Red, Orange, etc.
Weight
18.3 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2, ISO/IEC 15693, ISO/IEC 14443-A
Operating Frequency
860-960 MHz (Global), 13.56 MHz (HF)
IC Type
NXP NTAG 213, NXP ICODE SLIX
Memory
NTAG 213: EEPROM-1440 bits (180 bytes)
NTAG 215: EEPROM-4320 bits (540 bytes)
NTAG 216: EEPROM-7392 bits (924 bytes), ICODE SLIX: EEPROM-1024 bits (128 bytes)
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
0.1 cm to 5 cm(Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-35 °C to +85 °C / -31 °F to +185 °F
Recommended Storage
+25°C / 77°F, 40% RH
Shelf Life
2 years at +25°C / +77°F, 40% RH
IP Rating
IP65
Other Specification
Installation
Self-locking
Package Detail
50 pcs/bag or customized
Delivery Format
Single unit
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
For goods signs, logistics and transportation facilities, security inspections, petrochemical facilities, rail transit facilities, mobile communication facilities, anti-counterfeiting identification, biometric identification, security inspection facilities, power asset equipment management, etc
