SRSEAL5530

RFID Cable Tie Tag

Tired of lost assets, manual checks, and inefficient tracking? Meet the NFC Zip Tie Tag – the ultimate fusion of physical security and digital intelligence. This isn’t just an NFC tag; it’s a rugged, one-time-use lock that brings the power of contactless technology to your most critical assets.

Key Features & Benefits:

  • Tamper-Evident & Secure Locking Mechanism
    Once tightened, the zip tie cannot be reused. Any attempt to remove it requires cutting, providing a clear visual indicator of tampering. Perfect for safeguarding high-value or sensitive items.

  • Effortless Digital Interaction via NFC
    No need for batteries or a separate scanner. Just tap your phone to read or write data. It’s a seamless bridge between the physical item and its digital records.

  • Rugged & Weather-Resistant Design
    Built from durable nylon, our tags are resistant to water, dust, UV rays, and harsh chemicals. They perform reliably indoors, outdoors, and in demanding industrial environments.

  • Easy to Program & Use
    Use any free NFC writing app on your phone to program the tag with URLs, text, contact information, or automation commands. No technical expertise required.

  • Versatile Mounting & Application
    The flexible zip tie design allows you to securely fasten the tag to a vast range of items—from cables and pipes to tools, equipment, and bags—where traditional adhesive tags won’t work.

Physical Specification
Item
SRSEAL5530
Tag size
55*30 mm
Thickness
3 mm
Material
PP
Color
White, Black, Yellow, Green, Blue, Red, Orange, etc.
Weight
15.4 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2, ISO/IEC 15693, ISO/IEC 14443-A
Operating Frequency
860-960 MHz (Global), 13.56 MHz (HF)
IC Type
NXP NTAG 213, NXP ICODE SLIX
Memory
NTAG 213: EEPROM-1440 bits (180 bytes)
NTAG 215: EEPROM-4320 bits (540 bytes)
NTAG 216: EEPROM-7392 bits (924 bytes), ICODE SLIX: EEPROM-1024 bits (128 bytes)
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
0.1 cm to 5 cm(Depend on reader and environment)
Feature
Bulk identification
Environmental Specification
Operating Temperature
-35 °C to +85 °C / -31 °F to +185 °F
Recommended Storage
+25°C / 77°F, 40% RH
Shelf Life
2 years at +25°C / +77°F, 40% RH
IP Rating
IP65
Other Specification
Installation
Self-locking
Package Detail
50 pcs/bag or customized
Delivery Format
Single unit
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested, defective tags marked
Certification
CE Approved, RoHs Approved, etc.
Application
For goods signs, logistics and transportation facilities, security inspections, petrochemical facilities, rail transit facilities, mobile communication facilities, anti-counterfeiting identification, biometric identification, security inspection facilities, power asset equipment management, etc
