This innovative tag combines a high-performance UHF RFID inlay with a unique, mechanical self-locking housing. It is designed to be securely attached to an item and, once locked, cannot be removed without being intentionally destroyed, ensuring tamper-proof tracking. After the asset’s lifecycle, the tag can be manually unlocked and reused on a new item, dramatically reducing long-term costs.
Key Features & Benefits:
Reusable & Economical: Constructed from robust materials to withstand multiple lifecycles. Eliminate the recurring cost of disposable tags and reduce environmental waste.
Tamper-Evident & Self-Locking: The secure, one-time locking mechanism prevents unauthorized removal. Any attempt to tamper with the tag will render it unusable, providing a clear visual indicator of security breaches.
Superior UHF Performance: Features a high-sensitivity Alien Higgs® 3 or equivalent UHF chip, delivering exceptional read range and reliable data capture, even in challenging RF environments.
Rugged & Durable Design: Built with an ABS/PC plastic shell and an IP67 rating, this tag is dust-tight and can withstand temporary immersion in water. It is ideal for harsh industrial, logistics, and outdoor applications.
Effortless Deployment & Recovery: The simple “click-to-lock” design allows for quick application. When ready for reuse, the tag can be easily opened with a standard tool, streamlining your asset recovery process.
Global Compliance: Operates seamlessly in the 860-960 MHz frequency range, making it perfect for global supply chains and international asset tracking.
Physical Specification | ||
|---|---|---|
Item | SRSEAL5036 | |
Tag size | 50*36 mm | |
Thickness | 4 mm | |
Material | ABS | |
Color | White, Black, Yellow, Green, Blue, Red, Orange, etc. | |
Weight | 6.5 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2, ISO/IEC 15693, ISO/IEC 14443-A |
Operating Frequency | 860-960 MHz (Global), 13.56 MHz (HF) | |
IC Type | NXP NTAG 213, NXP ICODE SLIX | |
Memory | NTAG 213: EEPROM-1440 bits (180 bytes) NTAG 215: EEPROM-4320 bits (540 bytes) NTAG 216: EEPROM-7392 bits (924 bytes), ICODE SLIX: EEPROM-1024 bits (128 bytes) | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 0.1 cm to 5 cm(Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -35 °C to +85 °C / -31 °F to +185 °F |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
IP Rating | IP65 | |
Other Specification | Installation | Self-locking |
Package Detail | 50 pcs/bag or customized | |
Delivery Format | Single unit | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | For goods signs, logistics and transportation facilities, security inspections, petrochemical facilities, rail transit facilities, mobile communication facilities, anti-counterfeiting identification, biometric identification, security inspection facilities, power asset equipment management, etc |
