Upgrade your inventory, asset tracking, and supply chain logistics with our high-performance RFID Labels. Designed for accuracy, speed, and durability, these labels are the intelligent solution for businesses seeking to automate data capture and gain real-time visibility.
What is an RFID Label?
An RFID Label (Radio-Frequency Identification Label) is more than just a barcode. It combines a printed label with a embedded RFID inlay (chip and antenna). This allows information to be read wirelessly from a distance, without line-of-sight, enabling rapid bulk scanning and enhanced data capacity.
Key Features & Benefits:
Long-Range, Bulk Scanning: Read dozens of RFID Labels simultaneously from several meters away, dramatically reducing manual counting time and errors.
No Line-of-Sight Required: Unlike traditional barcodes, our RFID Labels can be read even when obscured, dirty, or inside packaging.
High Durability: Constructed with materials resistant to moisture, chemicals, abrasion, and extreme temperatures, ensuring reliable performance in harsh environments.
Rewriteable Data: The encoded data on each RFID Label can be updated dynamically, making it perfect for reusable assets and work-in-process tracking.
Customizable Options: Available in various sizes, frequencies (UHF, HF, NFC), chip types, and adhesives to perfectly match your specific application—from retail apparel tagging to industrial pallet tracking.
Physical Specification | ||
|---|---|---|
Item | SRU9929 | |
Antenna size | 22.5*22.5 mm | |
Tag size | 26*26 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | Alien Higgs 9 | |
Memory | Higgs 9: EPC-96(up to 496) bits; User- up to 688 bits; TID-48 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 6 m to 10 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | CD/DVD Management,etc. |
