Our UHF RFID Tag Sticker is a high-performance, flexible, and adhesive radio-frequency identification label designed for modern automated data capture. Operating in the Ultra-High Frequency (UHF) range (typically 860-960 MHz), it enables fast, long-range, and bulk reading of items without direct line-of-sight. This versatile sticker tag is the perfect tool for transforming how you manage inventory, assets, logistics, and retail operations.
Key Features & Benefits:
Long-Range & High-Speed Reading: Unlike barcodes or HF RFID, a single UHF RFID Tag Sticker can be read from several meters away. Scan hundreds of tagged items simultaneously within seconds—dramatically speeding up processes like warehouse inventory counts, shipment verification, and retail checkout.
Durable & Flexible Design: Constructed with a thin, flexible inlay and a strong adhesive backing, this UHF RFID Tag Sticker conforms easily to various surfaces, including cardboard boxes, plastic bins, metal assets (with appropriate anti-metal layer), and product packaging. It is built to withstand harsh environmental conditions.
Exceptional Data Capacity & Security: Each tag carries a unique, unalterable Electronic Product Code (EPC), allowing for precise item-level tracking. You can store critical data such as product details, manufacturing date, batch number, and maintenance history, enhancing traceability and security throughout your supply chain.
Easy Integration & Cost-Effective: Ready-to-use out of the box, simply peel and stick the UHF RFID Tag Sticker onto your items or assets. Its affordability, especially when deployed at scale, offers a rapid return on investment through labor savings, reduced errors, and optimized stock levels.
Reusable & Rewritable: Many of our UHF RFID Tag Stickers support memory rewrites, allowing you to update information and reuse tags across multiple lifecycles, reducing waste and long-term costs.
Physical Specification | ||
|---|---|---|
Item | SRU4444 | |
Antenna size | 44*44 mm | |
Tag size | 47*47 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 860-960 MHz (Global) | |
IC Type | NXP UCODE 8, NXP UCODE 9 | |
Memory | UCODE 8: EPC-128 bits; User-N/A; TID-96 bits , UCODE 9: EPC-96 bits; User-N/A; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 6 m to 10 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | CD/DVD Management,etc. |
