Our advanced family of UHF Tags is engineered to deliver reliable, long-range identification and tracking for the most demanding applications. Operating in the 860-960 MHz frequency range (ISO 18000-6C / EPC Class 1 Gen 2 standard), these passive UHF RFID tags enable rapid, simultaneous reading of multiple items—without direct line of sight—revolutionizing your asset and inventory management.
Unlock the Power of UHF RFID Technology:
Superior Read Range: Achieve read distances from 1 meter to over 10 meters (depending on model and reader setup), perfect for warehouse portals, conveyor belts, and supply chain checkpoints.
High-Speed Bulk Reading: Scan hundreds of UHF RFID tags per second, dramatically accelerating processes like inventory audits, shipment verification, and pallet tracking.
Robust & Versatile Designs: We offer a comprehensive range of UHF Tags in various forms: flexible dry/wet inlays for integration into labels, durable hard tags for harsh environments, and specialty designs for challenging surfaces like metal (on-metal tags) or liquid containers.
Global Compliance: Our tags are optimized for different regional power regulations (FCC, ETSI, etc.), ensuring consistent performance worldwide.
Ample Memory: Typically feature a user-programmable EPC memory (96-bit to 128-bit) and a unique TID, allowing for extensive item-level data encoding.
Physical Specification | ||
|---|---|---|
Item | SRH5215 | |
Antenna size | 52*15 mm | |
Tag size | 55*18 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 14443-A |
Operating Frequency | 13.56 MHz (HF) | |
IC Type | FM11RF08S | |
Memory | FM11RF08S: EEPROM-8K bits (1024 bytes) | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 6 m to 10 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | CD/DVD Management,etc. |
