Tired of inefficient, error-prone manual tracking? Our advanced RFID tags unlock a new era of automation, accuracy, and visibility for your business. Whether you’re managing inventory, tracking assets, securing documents, or optimizing supply chain logistics, our comprehensive range of UHF RFID tags is engineered for exceptional performance and reliability.
What are RFID Tags?
RFID (Radio-Frequency Identification) tags are intelligent data carriers that store and wirelessly transmit information to a reader via radio waves. Unlike barcodes, they don’t require line-of-sight scanning, enabling rapid, bulk reading of multiple items simultaneously—even through packaging or containers.
Core Benefits of Our RFID Tag Solutions:
Unmatched Efficiency: Scan hundreds of RFID tags in seconds from a distance, dramatically reducing labor time and costs associated with manual counts.
Pinpoint Accuracy: Achieve near 100% inventory accuracy. Eliminate human error and gain real-time, trustworthy data on asset location and status.
Robust & Durable Design: Our passive RFID tags require no internal power source and are built to withstand harsh environments. We offer tags resistant to chemicals, moisture, extreme temperatures, and physical impact.
Exceptional Read Range: Our UHF (Ultra-High Frequency) RFID tags offer long read ranges (up to 10+ meters depending on the model and environment), ideal for warehouse pallets, logistics, and large-scale asset tracking.
Versatile Application: From adhesive durable RFID labels for retail items to heavy-duty hard tags for machinery, and even laundry tags for textiles, we have a solution for virtually any surface or material.
Customizable & Flexible: Need a specific size, shape, encoding, or material? We provide custom RFID solutions tailored to your unique operational needs and integration requirements.
Physical Specification | ||
|---|---|---|
Item | SRH1809 | |
Antenna size | 18*09 mm | |
Tag size | 21*12 mm | |
Thickness | 11–18 mils / 279–463 microns | |
Material | Paper / PP / PET or customized | |
Adhesive | Solvent free permanent acrylic adhesive | |
Color | White, Transparent, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 14443-A |
Operating Frequency | 13.56 MHz (HF) | |
IC Type | FM11RF08S | |
Memory | FM11RF08S: EEPROM-8K bits (1024 bytes) | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range | 6 m to 10 m (Depend on reader and environment) | |
Feature | Bulk identification | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Bend Diameter | > 1.97” / 50 mm | |
Pressure | < 5N/mm2 | |
Drop Resistance | Per ASTM D5276 | |
Shelf Life | 2 years at +25°C / +77°F, 40% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Other Specification | Package Detail | 3000 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for dry inlay, wet inlay, label | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested, defective tags marked | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | CD/DVD Management,etc. |
