Elevate asset tracking in the demanding Oil and Gas industry with our RFID Flexible Metal Labels. Engineered for superior performance on curved and flexible metal surfaces, these tags provide unparalleled precision and durability. Streamline operations, enhance safety compliance, and optimize asset management with real-time visibility into your critical resources. Our RFID Flexible Metal Labels redefine the standards of efficiency and reliability, offering a tailor-made solution for the unique challenges of the Oil and Gas sector. Stay ahead in this dynamic industry with technology designed for precision, control, and success. Explore the future of intelligent asset tracking with our state-of-the-art RFID solutions, perfectly crafted for the rigors of Oil and Gas environments.
Physical Specification | ||
|---|---|---|
Item | SRUFLX6025 | |
Tag size | 60*25 mm | |
Thickness | 1.0 mm | |
Material | White PET | |
Adhesive | High tack adhesive with excellent adhesion / 3M (optional) | |
Color | White, etc. | |
Weight | 0.01 g | |
RFID Specification | Air Interface Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
Operating Frequency | 902-928 MHz (US), 865-868 MHz (EU) | |
IC Type | Impinj Monza R6, Impinj Monza R6-P | |
Memory | Monza R6: EPC-96 bits; User-N/A; TID-96 bits Monza R6-P: EPC-128(96) bits; User-32(64) bits; TID-96 bits | |
Write Endurance | 100,000 cycles | |
Data Retention | Up to 20 years | |
Read Range (Fixed reader) | US: On metal up to 8.0 m EU: On metal up to 5.0 m | |
Read Range (Handheld reader) | US: On metal up to 3.0 m EU: On metal up to 2.0 m | |
Feature | Workable on metallic curved surface | |
Environmental Specification | Operating Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
Operating Humidity | 20% to 60% RH | |
Recommended Storage | +25°C / 77°F, 40% RH | |
Shelf Life | 1 years at +20°C / +68°F, 50% RH | |
ESD Voltag Immunity | ±2 kV peak HBM | |
Vibration | MIL-STD-810G | |
IP Rating | IP68, tested for 5 hours in 1m deep water | |
Other Specification | Package Detail | 500 pcs/reel, vacuumed in ESD bag or customized |
Core Size | 76.2 mm / 3 in, etc. | |
Delivery Format | On reel for label | |
Printer Compatibility | SATO CL4NX, Zebra ZT410 Silverline, Postek TX3r, etc. | |
Installation | Clean and dry the surface before the mounting | |
Samples Policy | For free if stock available | |
Personalization | Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc. | |
Final Inspection | 100% tested | |
Certification | CE Approved, RoHs Approved, etc. | |
Application | Logistic management, Warehouse management, Apparel management, etc. |
